H3C S3600 Series User Manual

Operation Manual – AAA-RADIUS-HWTACACS-EAD
H3C S3600 Series Ethernet Switches-Release 1510
Chapter 1 AAA & RADIUS & HWTACACS
Configuration
1-42
Operation Command Description
Clear HWTACACS
message statistics
reset hwtacacs statistics
{ accounting | authentication
| authorization | all }
Delete buffered
non-response
stop-accounting requests
reset stop-accounting-buffer
{ hwtacacs-scheme
hwtacacs-scheme-name |
session-id session-id |
time-range start-time
stop-time | user-name
user-name }
You can execute the
reset command in
user view.
1.7 AAA & RADIUS & HWTACACS Configuration Example
1.7.1 Remote RADIUS Authentication of Telnet/SSH Users
 Note:
The configuration procedure for remote authentication of SSH users by RADIUS server
is similar to that for Telnet users. The following text only takes Telnet users as example
to describe the configuration procedure for remote authentication.
I. Network requirements
In the network environment shown in Figure 1-7, you are required to configure the
switch so that the Telnet users logging into the switch are authenticated by the RADIUS
server.
z A RADIUS server with IP address 10.110.91.164 is connected to the switch. This
server will be used as the authentication server.
z On the switch, set the shared key it uses to exchange messages with the
authentication RADIUS server to "expert".
You can use a CAMS server as the RADIUS server. You can select standard or
extended as the server-type in a RADIUS scheme.
On the RADIUS server:
z Set the shared key it uses to exchange messages with the switch to "expert".
z Set the authentication port number.
z Add Telnet user names and login passwords.
The Telnet user names added to the RADIUS server must be in the format of
userid@isp-name if you have configured the switch to include domain names in the
user names to be sent to the RADIUS server in the RADIUS scheme.
