Operation Manual – VLAN

H3C S3600 Series Ethernet Switches-Release 1510 Chapter 2

VLAN Configuration

2-3

2.2 Configuring a Port-Based VLAN

2.2.1 Configuring a Port-Based VLAN

I. Configuration prerequisites

Create a VLAN before configuring a port-based VLAN.

II. Configuration procedure

Table 2-4 Configure a port-based VLAN

Operation Command Description

Enter system view

system-view

—

Enter VLAN view

vlan vlan-id

—

Add Ethernet ports

to the specific

VLAN

port interface-list

Required

By default, all the ports belong

to the default VLAN

Caution:

The commands above are effective for access ports only. If you want to add trunk ports

or hybrid ports to a VLAN, you can use the

port trunk permit vlan command or the

port hybrid vlan command in Ethernet port view. For the configuration procedure,

refer to the section "Port Basic Configuration – Operation" in

H3C S3600 Series

Ethernet Switches Operation Manual

2.2.2 Protocol-Based VLAN Configuration Example

I. Network requirements

z Create VLAN 2 and VLAN 3 and specify the description string of VLAN 2 as home;

z Add Ethernet1/0/1 and Ethernet1/0/2 to VLAN 2 and add Ethernet1/0/3 and

Ethernet1/0/4 to VLAN 3.
