H3C S3600 Series User Manual

Operation Manual – Cluster
H3C S3600 Series Ethernet Switches-Release 1510 Chapter 1
Cluste
r
1-7
1.2 Cluster Configuration on Management Device
1.2.1 Management Device Cluster Configuration Tasks
Table 1-2 Management device cluster configuration tasks
Operation Description Related section
Enable NDP globally and on
specific ports
Required
Section 1.2.2 “Enabling NDP
Globally and on Specific Ports
”
Configure NDP-related
parameters
Required
Section 1.2.3 “Configuring
NDP-Related Parameters
”
Enable NTDP globally and on a
specific port
Required
Section
1.2.4 “Enabling NTDP
Globally and on a Specific Port
”
Configure NTDP-related
parameters
Required
Section
1.2.5 “Configuring
NTDP-Related Parameters
”
Enable the cluster function Required
Section
1.2.6 “Enabling the
Cluster Function
”
Configure cluster parameters Required
Section
1.2.7 “Configuring
Cluster Parameters
”
Configure interaction for the
cluster
Required
Section 1.2.8 “Configuring
Interaction for the Cluster
”
Configure NM interface for the
cluster
Optional
Section 1.2.9 “Configuring NM
Interface for the Cluster
”
 Note:
To reduce the risk of being attacked by malicious users against opened socket and
enhance switch security, the S3600 series Ethernet switches provide the following
functions, so that a cluster socket is opened only when it is needed:
z Opening UDP port 40000 (used for cluster) only when the cluster function is
implemented,
z Closing UDP port 40000 at the same time when the cluster function is closed.
On the management device, the preceding functions are implemented as follows:
z When you create a cluster by using the build or auto-build command, UDP port
40000 is opened at the same time.
z When you remove a cluster by using the undo build or undo cluster enable
command, UDP port 40000 is closed at the same time.
