H3C S3600 Series User Manual

Operation Manual – Mirroring
H3C S3600 Series Ethernet Switches-Release 1510 Chapter 1
Mirroring Configuration
1-16
1.3.4 Displaying Mirroring Parameter Settings
After the above configuration, you can use the display command in any view to view
the mirroring running information, so as to verify the configurations you made.
Table 1-12 Display mirroring parameter settings
Operation Command Description
Display parameter settings
of a mirroring group
display mirroring-group { group-id
| all | local | remote-destination |
remote-source }
Display parameter settings
of traffic mirroring
display qos-interface
{ interface-type interface-number |
unit-id } mirrored-to
The
command can
be executed
in any view.
1.4 Mirroring Configuration for S3600-SI
For mirroring features, refer to section 1.1 "Mirroring Overview".
1.4.1 Configuring Traffic Mirroring
The traffic mirroring configurations for S3600-SI are the same as those for S3600-EI.
Refer to section
1.3.1 “Configuring Traffic Mirroring” for details.
1.4.2 Configuring Port Mirroring
I. Configuration prerequisites
z The source port is determined and whether the packets to be mirrored are inbound,
outbound or both inbound and outbound is specified. Inbound means only to
mirror the packets received by the port; outbound means only to mirror the packets
sent by the port; both means to mirror the packets received and sent by the port.
z The destination port is determined.
II. Configuration procedure
Table 1-13 Configure port mirroring
Operation Command Description
Enter system view
system-view
—
Enter Ethernet port view of
the determined
destination port
interface
interface-type
interface-number
—
Define the current port as
the destination port
monitor-port
Required
LACP and STP must be disabled
on the destination port.
