H3C S3600 Series User Manual

Operation Manual – Mirroring
H3C S3600 Series Ethernet Switches-Release 1510 Chapter 1
Mirroring Configuration
1-13
Operation Command Description
Configure Trunk port to
permit packets from the
remote-probe VLAN
port trunk permit
vlan
remote-probe-vlan-id
Required
This configuration is necessary
for ports through which the
destination switch is
connected to the source switch
or an intermediate switch.
Exit the current view
quit
—
Configure a remote
destination mirroring
group
mirroring-group
group-id
remote-destination
Required
Configure the destination
port for remote mirroring
mirroring-group
group-id
monitor-port
monitor-port
Required
The destination port for remote
mirroring must be of the
Access type. LACP and STP
must be disabled on this port.
After you configure a port as
the destination port for remote
mirroring, the switch does not
allow you to change the port
type or its default VLAN ID.
Configure the
remote-probe VLAN for
the remote destination
mirroring group
mirroring-group
group-id
remote-probe vlan
remote-probe-vlan-id
Required
Display the configuration
of the remote destination
mirroring group
display
mirroring-group
remote-destination
Optional
This command can be
executed in any view.
 Note:
If the mac-address max-mac-count 0 command is executed on a port in a VLAN, it is
recommended not to configure this VLAN as the remote-probe VLAN. Otherwise,
remote mirroring may not work properly.
V. Configuration example
Network requirements:
z Switch A is connected to the data detect device through GigabitEthernet 1/1/2.
z GigabitEthernet 1/1/1, the Trunk port of Switch A, is connected to GigabitEthernet
1/1/1, the Trunk port of Switch B.
z GigabitEthernet 1/1/2, the Trunk port of Switch B, is connected to GigabitEthernet
1/1/1, the Trunk port of Switch C.
z GigabitEthernet 1/1/2, the port of Switch C, is connected to PC1.
