Operation Manual – QoS-QoS Profile
H3C S3600 Series Ethernet Switches-Release 1510 Chapter 1
QoS Configuration
1-16
ACL combination Form of the acl-rule argument
Apply a rule in a user-defined ACL
separately
user-group acl-number rule rule-id
Apply a rule in an IP ACL and a rule in
a Link ACL at the same time
ip-group acl-number rule rule-id
link-group acl-number rule rule-id
1.5.3 Configuration Example
z Ethernet1/0/1 of the switch is connected to the 10.1.1.1/24 network segment
z Remark the DSCP precedence of the traffic from the 10.1.1.1/24 network segment
to 56
Configuration procedure:
<H3C> system-view
System View: return to User View with Ctrl+Z.
[H3C] acl number 2000
[H3C-acl-basic-2000] rule permit source 10.1.1.1 0.0.0.255
[H3C-acl-basic-2000] quit
[H3C] interface Ethernet1/0/1
[H3C-Ethernet1/0/1] traffic-priority inbound ip-group 2000 dscp 56
1.6 Setting the Precedence of Protocol Packet
The protocol packet carries its own precedence. You can modify the precedence of the
protocol packet by setting its precedence. And then you can match the precedence with
the corresponding QoS action to perform the corresponding QoS operation on the
protocol packet.
1.6.1 Configuration Prerequisites
z The type of protocol whose precedence needs modification is specified
z The precedence value after modification is specified
1.6.2 Configuration Procedure
Table 1-10 Set the precedence of the protocol packet
Operation Command Description
Enter system
view
system-view
—
