H3C S3600 Series User Manual

Operation Manual – Voice VLAN
H3C S3600 Series Ethernet Switches-Release 1510 Chapter 1
Voice VLAN Configuration
1-4
Caution:
z If the voice traffic transmitted by an IP voice device is with VLAN tag, and the port
which the IP voice device is attached to is enabled with 802.1x authentication and
802.1x guest VLAN, assign different VLAN IDs for the voice VLAN, the default
VLAN of the port, and the 802.1x guest VLAN to ensure the effective operation of
these functions.
z If the voice traffic transmitted by the IP voice device is without VLAN tag, the default
VLAN of the port which the IP voice device is attached to can only be configured to
a voice VLAN to ensure the effective operation of the voice VLAN function. In this
case, the 802.1x authentication is unavailable.
1.2 Configuring Voice VLAN
1.2.1 Configuration Prerequisites
z Create the corresponding VLAN before configuring a voice VLAN.
z VLAN 1 is the default VLAN and do not need to be created. And VLAN 1 does not
support voice VLAN .
1.2.2 Configuring a Voice VLAN to Operate in Automatic Mode
Table 1-3 Configure a voice VLAN to operate in automatic mode
Operation Command Description
Enter system view
system-view
—
Enter Ethernet port view
interface interface-type
interface-number
Required
Enable the voice VLAN
function on a port
voice vlan enable
Required
By default, voice VLAN is
disabled.
Set the voice VLAN
operation mode on a
port to automatic.
voice vlan mode auto
Optional
The default voice VLAN
operation mode on a port is
automatic.
Quit to system view
quit
—
Set an OUI address that
can be identified by the
voice VLAN
voice vlan
mac-address oui mask
oui-mask [ description
text ]
Optional
By default, the switch
determines the voice traffic
according to the default OUI
address.
