Operation Manual – Login
H3C S3600 Series Ethernet Switches-Release 1510 Chapter 3
Logging in through Telnet
3-15
[H3C-ui-vty0] screen-length 30
# Set the maximum number of commands the history command buffer can store to 20.
[H3C-ui-vty0] history-command max-size 20
# Set the timeout time to 6 minutes.
[H3C-ui-vty0] idle-timeout 6
3.5 Telneting to a Switch
3.5.1 Telneting to a Switch from a Terminal
1) Assign an IP address to the interface of the management VLAN of a switch. This
can be achieved by executing the ip address command in VLAN interface view
after you log in through the Console port.
z Connect the serial port of your PC/terminal to the Console port of the switch, as
shown in
Figure 3-4
Console port
RS-232 port
Configuration cable
Console port
RS-232 port
Configuration cable
Figure 3-4 Diagram for establishing connection to a Console port
z Launch a terminal emulation utility (such as Terminal in Windows 3.X or
HyperTerminal in Windows 9X) on the PC, with the baud rate set to 9,600 bps,
data bits set to 8, parity check set to none, and flow control set to none.
z Turn on the switch and press Enter as prompted. The prompt (such as <H3C>)
appears, as shown in the following figure.
Figure 3-5 The terminal window
