1.10.1 Configuration Prerequisites
The queue-scheduling algorithm is specified: which queues adopt the WRR
queue-scheduling algorithm, which queues adopt the WFQ queue-scheduling
algorithm, and which queues adopt the SP queue-scheduling algorithm.
1.10.2 Configuration Procedure
Table 1-14 Configure queue scheduling in system view
Operation Command Description
Enter system view
system-view
—
Configure the queue
scheduling mode
queue-scheduler
{ strict-priority | wfq
queue0-width queue1-width
queue2-width queue3-width
queue4-width queue5-width
queue6-width queue7-width
| wrr queue0-weight
queue1-weight
queue2-weight
queue3-weight
queue4-weight
queue5-weight
queue6-weight
queue7-weight }
Required
In WRR or WFQ mode, if
the weight value or
minimum bandwidth of one
or more queues is set to 0,
SP algorithm is used for
this or these queues
By default, all the outbound
queues on the port adopt
the WRR queue scheduling
algorithm and their default
weight values are
1:2:3:4:5:9:13:15.
Display the
queue-scheduling
mode and related
parameters on the
switch
display queue-scheduler
Optional
You can execute the
display command in any
view.
Table 1-15 Configure queue scheduling in Ethernet port view
Operation Command Description
Enter system view
system-view
—
Enter Ethernet port
view
interface interface-type
interface-number
—
