H3C S3600 Series User Manual

Operation Manual – Mirroring
H3C S3600 Series Ethernet Switches-Release 1510 Chapter 1
Mirroring Configuration
1-12
Operation Command Description
Define the current VLAN as a
remote-probe VLAN
remote-probe vlan
enable
Required
Exit the current view
quit
—
Enter Ethernet port view of the
port connecting to the source
switch, destination switch or
other intermediate switch
interface interface-type
interface-number
—
Configure the current port as
Trunk port
port link-type trunk
Required
By default, the port
type is Access.
Configure Trunk port to permit
packets from the
remote-probe VLAN
port trunk permit vlan
remote-probe-vlan-id
Required
This configuration is
necessary for ports on
the intermediate switch
that are connected to
the source switch, the
destination switch or
other intermediate
switch.
IV. Configuring RSPAN on the destination switch
Table 1-11 Configure RSPAN on the destination switch
Operation Command Description
Enter system view
system-view
—
Create a VLAN and enter
VLAN view
vlan vlan-id
vlan-id is the ID of the
remote-probe VLAN to be
defined.
Define the current VLAN
as a remote-probe VLAN
remote-probe vlan
enable
Required
Exit the current view
quit
—
Enter Ethernet port view
of the port connecting to
the source switch or an
intermediate switch
interface
interface-type
interface-number
—
Configure the current port
as Trunk port
port link-type trunk
Required
By default, the port type is
Access.
