Operation Manual – Auto Detect

H3C S3600 Series Ethernet Switches-Release 1510 Chapter 2

Auto Detect Implementation

2-6

2.4.1 Configuring the Auto Detect Function for VLAN Interface Backup

 Note:

You need to create the detecting group and perform configurations concerning VLAN

interfaces before the following operations.

Table 2-3 Configure the auto detect function for VLAN interface backup

Operation Command Description

Enter system view

system-view

—

Enter VLAN

interface view

interface vlan-interface

vlan_id

—

Enable the auto

detect function to

implement VLAN

interface backup

standby detect-group

group-number

Required

This operation is only needed

on the secondary VLAN

interface.

2.4.2 Configuration Example

I. Network requirements

z Configure a static route between Switch C and Switch A.

z Create detecting group 10 on Switch A to detect the connectivity between Switch

B and Switch C.

z Configure VLAN 1 interface to be the primary interface, which is enabled when the

result of detecting group 10 is reachable.

z Configure VLAN 2 interface to be the secondary interface, which is enabled when

the result of the detecting group 10 is unreachable.

z Make sure the routes between Switch A, Switch B, and Switch C are reachable;

and those between Switch A, Switch D, and Switch C are also reachable.
