Operation Manual – System Maintenance and Debugging

H3C S3600 Series Ethernet Switches-Release 1510

Chapter 1 BootROM and Host Software

1-9

 Note:

You can use one PC as both the configuration device and the TFTP server.

Step2: Run the TFTP server program on the TFTP server, and specify the path of the

program to be downloaded.

Caution:

TFTP server program is not provided with the H3C Series Ethernet Switches.

Step 3: Run the HyperTerminal program on the configuration PC. Start the switch. Then

enter the BOOT Menu.

At the prompt "Enter your choice(0-9):" in the BOOT Menu, press <6> or <Ctrl+U>, and

then press <Enter> to enter the BootROM update menu shown below:

Bootrom update menu:

1. Set TFTP protocol parameter

2. Set FTP protocol parameter

3. Set XMODEM protocol parameter

0. Return to boot menu

Enter your choice(0-3):

Step 4: Enter 1 in the above menu to download the BootROM using TFTP. Then set the

following TFTP-related parameters as required:

Load File name :S3600.btm

Switch IP address :1.1.1.2

Server IP address :1.1.1.1

Step 5: Press <Enter>. The system displays the following information:

Are you sure to update your bootrom?Yes or No(Y/N)

Step 6: Enter Y to start file downloading or N to return to the Bootrom update menu. If

you enter Y, the system begins to download and update the BootROM. Upon

completion, the system displays the following information:

Loading........................................done

Bootrom updating..........done!

III. Loading host software

Follow these steps to load the host software.
