Operation Manual – VRRP

H3C S3600 Series Ethernet Switches-Release 1510 Chapter 1

VRRP Configuration

1-16

# Create backup group 1.

[LSW-A-Vlan-interface2] vrrp vrid 1 virtual-ip 202.38.160.111

# Set the priority for backup group 1.

[LSW-A-Vlan-interface2] vrrp vrid 1 priority 150

# Create backup group 2.

[LSW-A-Vlan-interface2] vrrp vrid 2 virtual-ip 202.38.160.112

z Configure Switch B.

# Configure VLAN 2.

<LSW-B> system-view

System View: return to User View with Ctrl+Z.

[LSW-B] vlan 2

[LSW-B-vlan2] port Ethernet 1/0/6

[LSW-B-vlan2] quit

[LSW-B] interface vlan-interface 2

[LSW-B-Vlan-interface2] ip address 202.38.160.2 255.255.255.0

# Create backup group 1.

[LSW-B-Vlan-interface2] vrrp vrid 1 virtual-ip 202.38.160.111

# Create backup group 2.

[LSW-B-Vlan-interface2] vrrp vrid 2 virtual-ip 202.38.160.112

# Set the priority for backup group 2.

[LSW-B-Vlan-interface2] vrrp vrid 2 priority 110

 Note:

Normally, multiple backup groups are used in actual use.

1.4.4 Port Tracking Configuration Example

I. Network requirements

z Backup group 1 comprises two switches, which operate as the master switch and

the backup switch.

z The actual IP addresses of the master and the backup switches are 10.100.10.2

and 10.100.10.3 respectively.

z The master switch is connected to the upstream network through its Ethernet1/0/1

port. The backup switch is connected to the upstream network through its

Ethernet1/0/2 port.

z The virtual router IP address of the backup group is 10.100.10.1.
