H3C S3600 Series User Manual

Operation Manual – ACL
H3C S3600 Series Ethernet Switches-Release 1510 Chapter 1
ACL Configuration
1-15
Keyword CoS in decimal CoS in binary
spare
2 010
excellent-effort
3 011
controlled-load
4 100
video
5 101
voice
6 110
network-management
7 111
When you define an ACL rule using the rule command with the rule-id argument
provided,
z If the ACL rule identified by the rule-id argument already exists, the settings
specified in the rule command overwrite the corresponding settings of the existing
rule. And the existing settings remain unchanged if the corresponding settings are
not specified in the command.
z If the ACL rule identified by the rule-id argument does not exist, you will create a
new rule.
z The content of a modified or created rule cannot be identical with the content of
any existing rules; otherwise the rule modification or creation will fail, and the
system prompts that the rule already exists.
If you do not specify the rule-id argument when creating an ACL rule, the rule will be
numbered automatically.
1.5.3 Configuration Example
# Configure ACL 4000 to deny packets sourced from the MAC address 000d-88f5-97ed,
destined for the MAC address 0011-4301-991e, and with their 802.1p priority being 3.
<H3C> system-view
[H3C] acl number 4000
[H3C-acl-ethernetframe-4000] rule deny cos 3 source 000d-88f5-97ed
ffff-ffff-ffff dest 0011-4301-991e ffff-ffff-ffff
[H3C-acl-ethernetframe-4000] display acl 4000
Ethernet frame ACL 4000, 1 rule
Acl's step is 1
rule 0 deny cos excellent-effort source 000d-88f5-97ed ffff-ffff-ffff dest
0011-4301-991e ffff-ffff-ffff
1.6 User-Defined ACL Configuration
A user-defined ACL filters packets by comparing specific bytes in packet headers with
specified string.
