H3C S3600 Series User Manual

Operation Manual – VRRP
H3C S3600 Series Ethernet Switches-Release 1510 Chapter 1
VRRP Configuration
1-10
Operation Command Description
Enable the auto
detect function for
VRRP
vrrp vrid virtual-router-id track
detect-group group-number [ reduced
value-reduced ]
Required
 Note:
A detecting group can be used to detect up to eight Layer 3 interfaces.
1.3 Displaying and Debugging VRRP
After the above configurations, you can execute the display command in any view to
view VRRP configuration and verify the configuration effect. And you can execute the
reset command in user view to clear the VRRP statistics.
Table 1-7 Display and debug VRRP
Operation Command Description
Display VRRP
state information
and statistics
information
display vrrp [ interface
vlan-interface vlan-id |
statistics [ vlan-interface
vlan-id ] ] [ virtual-router-id ]
The display command can be
executed in any view.
Clear VRRP
statistics
reset vrrp statistics
[ vlan-interface vlan-id ]
[ virtual-router-id ]
The reset command can be
executed in user view.
1.4 VRRP Configuration Example
1.4.1 Single-VRRP Backup Group Configuration
I. Network requirements
Host A uses the VRRP virtual router comprising switch A and switch B as its default
gateway to visit host B on the Internet.
The information about the VRRP backup group is as follows:
z VRRP backup group ID: 1
z Virtual router IP address: 202.38.160.111
z Master switch: Switch A
z Backup switch: Switch B
z Preemptive mode: enabled
