H3C S3600 Series User Manual

Operation Manual – VLAN
H3C S3600 Series Ethernet Switches-Release 1510 Chapter 2
VLAN Configuration
2-2
II. Configuration procedure
Table 2-2 Basic VLAN interface configuration
Operation Command Description
Enter system view
system-view
—
Create a VLAN
interface and enter
VLAN interface
view
interface Vlan-interface
vlan-id
Required
The
vlan-id argument ranges
from 1 to 4,094.
Specify the
description string
for the current
VLAN interface
description text
Optional
By default, the description
string of a VLAN interface is
the name of this VLAN
interface
Disable the VLAN
interface
shutdown
Optional
Enable the VLAN
Interface
undo shutdown
Optional
Note that the operation of enabling/disabling a VLAN interface does not influence the
enabling/disabling states of the Ethernet ports belonging to this VLAN.
By default, the VLAN interface’s management state is enabled. In this case, the
physical state of the VLAN interface is affected by the ports state in the VLAN. When all
the Ethernet ports of a VLAN are down, the VLAN interface of the VLAN is down, that is,
the VLAN interface is disabled; when one or more Ethernet ports of a VLAN are up, the
VLAN interface of the VLAN is up, that is, the VLAN interface is enabled.
If you disable the VLAN interface’s management state, the VLAN interface will always
be down, regardless of the states of the ports in the VLAN.
2.1.3 Displaying VLAN Configuration
After the configuration above, you can execute the display command in any view to
display the running status after the configuration, so as to verify the configuration.
Table 2-3 Display VLAN configuration
Operation Command Description
Display the VLAN
interface information
display interface
Vlan-interface
[ vlan-id ]
Display the VLAN
information
display vlan [ vlan-id [ to
vlan-id ] | all | dynamic | static ]
You can execute the
display command in
any view.
