H3C S3600 Series User Manual

Operation Manual – PoE-PoE Profile
H3C S3600 Series Ethernet Switches-Release 1510 Chapter 2
PoE Profile Configuration
2-1
Chapter 2 PoE Profile Configuration
2.1 Introduction to PoE Profile
On a large-sized network or a network with mobile users, to help network
administrators to monitor the PoE features of the switch, S3600 series Ethernet
switches provide the PoE profile features.
Features of PoE profile:
z Various PoE profiles can be created. PoE policy configurations applicable to
different user groups are stored in the corresponding PoE profiles. These PoE
profiles can be applied to the ports used by the corresponding user groups.
z When users connect a PD to a PoE-profile-enabled port, the PoE configurations in
the PoE profile will be enabled on the port.
2.2 PoE Profile Configuration Tasks
Table 2-1 Configure PoE profile
Operation Command Description
Enter system view
system-view
—
Create a PoE profile
poe-profile
profilename
Required
Enter PoE profile view
while creating the PoE
profile
Enable the PoE
feature on a port
poe enable
Required
The PoE feature on a
port is disabled by
default
Configure PoE
mode for Ethernet
ports
poe mode { signal |
spare }
Optional
By default, PoE mode
is set to be signal
Configure the PoE
priority for Ethernet
ports
poe priority
{ critical | high |
low }
Optional
By default, PoE priority
is set to low
Configure
the
relevant
features in
PoE
profile
Configure the
maximum power for
Ethernet ports
poe max-power
max-power
Optional
By default, maximum
power is set to be
15,400 mW
Quit system view
quit
—
