1.3.3 Configuring RSPAN
I. Configuration prerequisites
z The source switch, intermediate switch, and the destination switch are
determined.
z The source port, the reflector port, the destination port, and the remote-probe
VLAN are determined.
z Layer 2 interoperability is ensured by configuration between the source and
destination switches over the remote-probe VLAN
z The direction of the packets to be monitored is determined.
z The remote-probe VLAN is enabled.
II. Configuring RSPAN on the source switch
Table 1-9 Configure RSPAN on the source switch
Operation Command Description
Enter system view
system-view
—
Create a VLAN and enter
the VLAN view
vlan vlan-id
vlan-id is the ID of the
remote-probe VLAN to be
defined.
Define the current VLAN
as the remote-probe
VLAN
remote-probe vlan
enable
Required
Exit the current view
quit
—
Enter the port view of the
port that connects to the
intermediate switch or
destination switch
interface interface-type
interface-number
—
Configure the current port
as Trunk port
port link-type trunk
Required
By default, the port type is
Access.
Configure Trunk port to
permit packets from the
remote-probe VLAN
port trunk permit vlan
remote-probe-vlan-id
Required
This setting is required for
the source switch port
that connects to the
intermediate switch or
destination switch.
Exit current view
quit
—
Configure a remote
source mirroring group
mirroring-group group-id
remote-source
Required
Configure a source port
for remote mirroring
mirroring-group group-id
mirroring-port
mirroring-port-list { both |
inbound | outbound }
Required
