H3C S3600 Series User Manual

Operation Manual – ACL
H3C S3600 Series Ethernet Switches-Release 1510 Chapter 1
ACL Configuration
1-13
A Layer 2 ACL can be numbered from 4000 to 4999.
1.5.1 Configuration Preparation
To configure a time range-based Layer 2 ACL rule, you need to create the
corresponding time ranges first. For information about time range configuration, refer to
section
1.2 “Time Range Configuration”.
The settings to be specified in the rule, such as source and destination MAC addresses,
VLAN priorities, and Layer 2 protocol types, are determined.
1.5.2 Configuration Procedure
Table 1-12 Define a Layer 2 ACL rule
Operation Command Description
Enter system view
system-view
—
Create a Layer 2 ACL or enter
layer 2 ACL view
acl number acl-number
Required
Define an ACL rule
rule [ rule-id ] { permit | deny }
rule-string
Required
Assign a description string to
the ACL rule
rule rule-id comment text
Optional
Assign a description string to
the ACL
description text
Optional
The rule-string argument of the rule command can be a combination of the
arguments/keywords described in
Table 1-13.
Table 1-13 Layer 2 ACL rule information
Parameter Type Function Description
format-type
Link layer
encapsulation
type
Specifies the
link layer
encapsulation
type for the
ACL rule
This argument can be
802.3/802.2, 802.3, ether_ii,
or snap.
lsap lsap-code
lsap-wildcard
lsap field
Specifies the
lsap field for
the ACL rule
lsap-code: Encapsulation
format of data frames, a 16-bit
hexadecimal number.
lsap-wildcard: Mask of the
lsap value, a 16-bit
hexadecimal number used to
specify the mask bits.
