H3C S3600 Series User Manual

Operation Manual – VLAN
H3C S3600 Series Ethernet Switches-Release 1510 Chapter 2
VLAN Configuration
2-6
II. Configuration procedure
Table 2-6 Associate a port with the protocol-based VLAN
Operation Command Description
Enter system view
system-view
—
Enter port view
interface interface-type interface-number
Required
Associate a port with
the protocol-based
VLAN
port hybrid protocol-vlan vlan vlan-id
{
protocol-index [ to protocol-end ] | all }
Required
Caution:
For the operation of adding a hybrid port to the VLAN, refer to the section “Port Basic
Configuration” in this manual.
2.3.3 Displaying Protocol-Based VLAN Configuration
After the configuration above, you can execute the display command in any view to
display the running status, so as to verify the configuration.
Table 2-7 Display VLAN configuration
Operation Command Description
Display the information
about the protocol-based
VLAN
display vlan [ vlan-id [ to
vlan-id
] | all | static |
dynamic
]
Display the protocol
information and protocol
indexes configured on the
specified VLAN
display protocol-vlan vlan
{ vlan-id [ to vlan-id ] | all }
Display the protocol
information and protocol
indexes configured on the
specified port
display protocol-vlan
interface
{ interface-type
interface-number
[ to
interface-type
interface-number
] | all }
You cam execute
the
display
command in any
view
2.3.4 Protocol-Based VLAN Configuration Example
I. Standard-template-based protocol VLAN configuration example
1) Network requirements
