H3C S3600 Series User Manual

Operation Manual – Web Cache Redirection
H3C S3600 Series Ethernet Switches-Release 1510
Chapter 1 Web Cache Redirection
Configuration
1-3
Operation Command Description
Configure Web
cache parameters
webcache address
ip-address mac
mac-address vlan vlan-id
[ tcpport tcpport-num ]
Required
Quit to system view
quit
—
Specify a VLAN
whose HTTP traffic
is to be redirected
to the Web cache
webcache redirect-vlan
vlan-id
Required
You can specify multiple
VLANs for Web cache
redirection so that the HTTP
traffic of the users in these
VLANs can be redirected to
the Web cache.
By default, the HTTP traffic is
not redirected to the Web
cache.
Display Web cache
redirection
configuration and
the state of the
Web cache
display webcache
Optional
This command can be
executed in any view.
 Note:
z Web cache redirection configurations made in Ethernet port view and system view
come into the same effect.
z If the configured Web cache is inaccessible, Web cache redirection cannot be
enabled.
z A switch supports only one Web cache configuration. If you configure a new Web
cache, the new configuration will replace the old one.
z If the VLAN where Web cache is located does not have the corresponding VLAN
interface on the switch, this configuration will be failed.
z If the VLAN interface is not up, Web cache redirection will be failed.
z You can use the undo webcache all command to remove all Web cache
redirection configurations.
1.2.3 Configuration Example
I. Networking requirements
In a company, the marketing department is located at VLAN10 connected to Ethernet
1/0/1 of the switch, R&D department is located at VLAN20 connected to Ethernet1/0/2,
and President’s office at VLAN30 connected to Ethernet1/0/3. VLAN10 is in the
network segment 10.15.17.1/24, VLAN20 in 10.15.18.1/24, and VLAN30 in
