H3C S3600 Series User Manual

Operation Manual – QoS-QoS Profile
H3C S3600 Series Ethernet Switches-Release 1510 Chapter 1
QoS Configuration
1-15
1.5.1 Configuration Prerequisites
z ACL rules used for traffic identifying are defined. Refer to the ACL module in the
manual for defining ACL rules
z The type and value of the precedence that the packets matching ACL rules are
remarked are determined
z The ports which need this configuration are defined
1.5.2 Configuration Procedure
Table 1-8 Configure priority remark
Operation Command Description
Enter system view
system-view
—
Enter Ethernet port
view
interface interface-type
interface-number
—
Use ACL rules in
traffic identifying and
specify a new
precedence for the
packet matching the
ACL rules
traffic-priority { inbound |
outbound } acl-rule { { dscp
dscp-value | ip-precedence
{ pre-value | from-cos } } | cos
{ pre-value | from-ipprec } |
local-precedence pre-value }*
Required
Display the parameter
configurations of
priority remark
display qos-interface
{ interface-type interface-number
| unit-id } traffic-priority
Display all the QoS
settings of the port
display qos-interface
{ interface-type interface-number
| unit-id } all
Optional
You can execute the
display command in
any view
acl-rule: Applied ACL rules which can be the combination of various ACL rules. The
way of combination is described in the following table:
Table 1-9 Ways of applying combined ACLs
ACL combination Form of the acl-rule argument
Apply all the rules in an IP ACL
separately
ip-group acl-number
Apply a rule in an IP ACL separately
ip-group acl-number rule rule-id
Apply all the rules in a Link ACL
separately
link-group acl-number
Apply a rule in a Link ACL separately
link-group acl-number rule rule-id
Apply all the rules in a user-defined
ACL separately
user-group acl-number
