H3C S3600 Series User Manual

Operation Manual – QoS-QoS Profile
H3C S3600 Series Ethernet Switches-Release 1510 Chapter 1
QoS Configuration
1-18
1.7.2 Configuration Procedure
Table 1-11 Configure port rate limit
Operation Command Description
Enter system
view
system-view
—
Enter Ethernet
port view
interface interface-type
interface-number
—
Configure
port-based rate
limit
line-rate { inbound |
outbound } target-rate
Required
z target-rate: Total rate to limit
packet sending and receiving on
the port, in Kbps. The granularity
of rate limit is 64 Kbps. If the
number you input is in the range
of N*64 to (N+1)*64 (N is a
natural number), the switch will
set the value to (N+1)*64 Kbps
automatically
z The rate range of 100 M
Ethernet ports is from 64 to
99,968
z The rate range of Gigabit
Ethernet ports is in from 64 to
1,000,000
1.7.3 Configuration Example
z Set rate limit in the outbound direction of Ethernet1/0/1 on the switch
z The limit rate is 1 Mbps (1,024 Kbps)
Configuration procedure:
<H3C> system-view
System View: return to User View with Ctrl+Z.
[H3C] interface Ethernet1/0/1
[H3C-Ethernet1/0/1] line-rate outbound 1024
1.8 Configuring TP
Refer to section 1.1.8 "TP" for the introduction to TP.
1.8.1 Configuration Prerequisites
z ACL rules used for traffic identifying are defined. Refer to the ACL module in the
manual for defining ACL rules
z The limit rate for TP, the actions for the packets within the specified traffic and the
actions for the packets beyond the specified traffic have been specified.
