H3C S3600 Series User Manual

Operation Manual – System Maintenance and Debugging
H3C S3600 Series Ethernet Switches-Release 1510 Chapter 4
Device Management
4-4
Table 4-7 Display the operating status of the device management
Operation Command Description
Display the APP to be
adopted at next startup
display boot-loader [ unit
unit-id ]
Display the module type
and operating status of
each board
display device [ manuinfo
[ unit unit-id ] | unit unit-id ]
Display CPU usage of a
switch
display cpu [ unit unit-id ]
Display the operating
status of the fan
display fan [ unit unit-id
[ fan-id ] ]
Display memory usage of
a switch
display memory [ unit unit-id ]
Display the operating
status of the power supply
display power [ unit unit-id
[ power-id ] ]
Display system diagnostic
information or save
system diagnostic
information to a file with
the extension .diag into
the Flash memory
display
diagnostic-information
Display enabled
debugging on a specified
switch or all switches in
the fabric
display debugging { fabric |
unit unit-id } [ interface
interface-type interface-number
| module-name ]
Display enabled
debugging on all switches
in the fabric by modules
display debugging fabric
by-module
You can execute
the display
command in any
view.
4.4 Remote Switch Upgrade Configuration Example
I. Network requirements
Telnet to the switch from a PC remotely and download applications from the FTP server
to the Flash memory of the switch. Update the switch software by using the device
management commands through CLI.
The switch acts as the FTP client, and the remote PC serves as both the configuration
PC and the FTP server.
Perform the following configuration on the FTP server.
z Configure an FTP user, whose name is switch and password is hello. Authorize
the user with the read-write right on the directory switch on the PC.
