Operation Manual – PoE-PoE Profile
H3C S3600 Series Ethernet Switches-Release 1510 Chapter 2
PoE Profile Configuration
2-3
Caution:
z PoE profile configuration is a global configuration, and applies synchronously in the
intelligent resilient framework (IRF) system.
z Combination of Unit creates a new Fabric. In the newly created Fabric, the PoE
profile configuration of the Unit with the smallest Unit ID number will become the
PoE profile configuration for the Fabric currently in use.
z Split of Fabric results in many new Fabrics. In each newly created Fabric, the PoE
profile configuration of each Unit remains the same as it was before the split.
2.3 Displaying PoE Profile Configuration
After the above configuration, execute the display command in any view to see the
running status of the PoE profile and verify the effect of the configuration by checking
the displayed information.
Table 2-2 Display the PoE profile configuration
Operation Command Description
Display the detailed
information about the PoE
profiles created on the
switch
display poe-profile
{ all-profile | interface
interface-type
interface-number | name
profile-name }
You can execute
the display
command in any
view
2.4 PoE Profile Configuration Example
I. Network requirements
Ethernent1/0/1 through Ethernet1/0/10 of the S3600-28P-PWR-EI switch are used by
users of group A, who have the following requirements:
z The PoE function can be enabled on all ports in use.
z Signal cables are used to supply power.
z The PoE priority for Ethernet1/0/1 through Ethernet1/0/5 is Critical, whereas the
PoE priority for Ethernet1/0/6 through Ethernet1/0/10 is High.
z The maximum power for Ethernet1/0/1 through Ethernet1/0/5 ports is 3,000 mW,
whereas the maximum power for Ethernet1/0/6 through Ethernet1/0/10 is 15,400
mW.
Based on the above requirements, two PoE profiles are made for users of group A.
z Apply PoE profile 1 for Ethernet1/0/1 through Ethernet 1/0/5;
z Apply PoE profile 2 for Ethernet1/0/6 through Ethernet 1/0/10.
