H3C S3600 Series User Manual

Operation Manual – File System Management
H3C S3600 Series Ethernet Switches-Release 1510 Chapter 2
FTP/TFTP Lighting Configuration
2-2
Figure 2-1 Clockwise rotating of the seven-segment digital LED
Table 2-1 Configuration for file upload from an FTP client to the switch acting as FTP
server
Device To do… Use the command… Remarks
Enable FTP server
ftp sever enable
Required
By default, FTP
server is disabled.
Add a local user and
enter local user view
local-user
user-name
Required
Set a password for
the local user
password { simple |
cipher } password
Required
FTP
server
(S3600)
Set the password
display mode for local
users
local-user
password-display-
mode { auto |
cipher-force }
Optional
By default, the mode
is auto (that is, the
switch displays user
passwords in the
modes configured
when the passwords
are set).
Log into the remote
FTP server
—
Required
For detailed
configuration, refer to
the configuration
instruction relevant to
FTP client.
FTP client
Upload file from the
FTP client to the FTP
server
—
Required
For detailed
configuration, refer to
the configuration
instruction relevant to
FTP client.
II. Enabling FTP client on the switch
After FTP client is enabled on an S3600 switch, the seven-segment digital LED on the
front panel of the switch will rotate clockwise when the FTP client (the S3600 switch) is
downloading file from an FTP server, and will stop rotating when the file downloading is
finished, as show in
Figure 2-1.
