H3C S3600 Series User Manual

Operation Manual – Voice VLAN
H3C S3600 Series Ethernet Switches-Release 1510 Chapter 1
Voice VLAN Configuration
1-3
Table 1-2 Matching relationship between port modes and voice traffic types
Port voice
VLAN
mode
Voice
traffic type
Port type Supported or not
Access Not supported
Trunk
Supported
Make sure the default VLAN of the port
exists and is not a voice VLAN. And the
access port permits the traffic of the
default VLAN.
Tagged
voice traffic
Hybrid
Supported
Make sure the default VLAN of the port
exists and is not a voice VLAN. The
default VLAN must be in the list of the
tagged VLANs whose traffic is permitted
by the access port.
Access
Trunk
Automatic
mode
Untagged
voice traffic
Hybrid
Not supported, because the default VLAN
of the port must be a voice VLAN and the
access port is in the voice VLAN. This can
be done by adding the port to the voice
VLAN manually.
Access Not supported
Trunk
Supported
Make sure the default VLAN of the port
exists and is not a voice VLAN. And the
access port permits the traffic of the
default VLAN.
Tag voice
traffic
Hybrid
Supported
Make sure the default VLAN of the port
exists and is in the list of the tagged
VLANs whose traffic is permitted by the
access port.
Access
Supported
Make sure the default VLAN of the port is
a voice VLAN.
Trunk
Supported
Make sure the default VLAN of the port is
a voice VLAN and the port permits the
traffic of the VLAN.
Manual
mode
Untag voice
traffic
Hybrid
Supported
Make sure the default VLAN of the port is
a voice VLAN and is in the list of untagged
VLANs whose traffic is permitted by the
port.
