Operation Manual – System Maintenance and Debugging

H3C S3600 Series Ethernet Switches-Release 1510

Chapter 1 BootROM and Host Software

1-4

3. Set XMODEM protocol parameter

0. Return to boot menu

Enter your choice(0-3):

Step 2: Press 3 in the above menu to download the BootROM using XModem. The

system displays the following setting menu for download baudrate:

Please select your download baudrate:

1.* 9600

2. 19200

3. 38400

4. 57600

5. 115200

0. Return

Enter your choice (0-5):

Step 3: Choose an appropriate download baudrate. For example, if you press 5, the

baudrate 115200 bps is chosen and the system displays the following information:

Download baudrate is 115200 bps

Please change the terminal's baudrate to 115200 bps and select XMODEM protocol

Press enter key when ready

 Note:

If you have chosen 9600 bps as the download baudrate, you need not modify the

HyperTerminal’s baudrate, and therefore you can skip Step 4 and 5 below and proceed

to Step 6 directly. In this case, the system will not display the above information.

Following are configurations on PC. Take the HyperTerminal in Windows operating

system as an example.

Step 4: Choose [File/Properties] in HyperTerminal, click <Configure> in the pop-up

dialog box, and then select the baudrate of 115200 bps in the Console port

configuration dialog box that appears, as shown in

Figure 1-1, Figure 1-2.
