VFP Instruction Execution

ID012310 Non-Confidential, Unrestricted Access

For the following two-cycle, double-precision, short vector instruction, the LEN field contains

b011, selecting a vector length of four iterations:

FMULD D4, D8, D12

The FMULD instruction performs the following operations:

FMULD D4, D8, D12

FMULD D5, D9, D13

FMULD D6, D10, D14

FMULD D7, D11, D15

In full-compliance mode, the source scoreboard clears the source registers of each iteration in

the first Execute 1 cycle of the iteration.

In RunFast mode, only the third iteration source registers, D10 and D14, and the fourth iteration

source registers, D11 and D15, are locked. The source scoreboard clears D10 and D14 in the

first Execute 1 cycle and clears D11 and D15 in the third Execute 1 cycle of the instruction.

4- -

5 Iteration 3 registers -

6- -

7 Iteration 4 registers -

8- -

Table 21-5 Double-precision source register clearing for two-cycle instructions

Execute 1 cycle

Source registers cleared in Execute 1 stage of each iteration

Full-compliance mode RunFast mode

ARM ARM1176JZF-S User Manual
