H3C S3600 Series User Manual

Operation Manual – ACL
H3C S3600 Series Ethernet Switches-Release 1510 Chapter 1
ACL Configuration
1-10
Table 1-8 TCP/UDP-specific ACL rule information
Parameter Type Function Description
source-port
operator port1
[ port2 ]
Source port
Defines the
source port
information of
UDP/TCP
packets
destination-port
operator port1
[ port2 ]
Destination
port
Defines the
destination port
information of
UDP/TCP
packets
The value of operator can
be lt (less than), gt (greater
than), eq (equal to), neq
(not equal to) or range
(within the range of). Only
the “range” operator
requires two port numbers
as the operands. Other
operators require only one
port number as the
operand.
port1 and port2: TCP/UDP
port numbers, expressed as
port names or port
numbers. When expressed
as numbers, the value
range is 0 to 65535.
established
TCP
connection
flag
Specifies that the
rule is applicable
only to the first
SYN segment for
establishing a
TCP connection
TCP-specific argument
When using port name to specify TCP/UDP ports, you can define the following
information.
Table 1-9 TCP/UDP port values
Protocol type Value
TCP
CHARgen (19), bgp (179), cmd (514), daytime (13), discard (9),
domain (53), echo (7), exec (512), finger (79), ftp (21), ftp-data
(20), gopher (70), hostname (101), irc (194), klogin (543),
kshell (544), login (513), lpd (515), nntp (119), pop2 (109), pop3
(110), smtp (25), sunrpc (111), tacacs (49), talk (517), telnet
(23), time (37), uucp (540), whois (43), www (80)
UDP
biff (512), bootpc (68), bootps (67), discard (9), dns (53), dnsix
(90), echo (7), mobilip-ag (434), mobilip-mn (435), nameserver
(42), netbios-dgm (138), netbios-ns (139), netbios-ssn (139),
ntp (123), rip (520), snmp (161), snmptrap (162), sunrpc (111),
syslog (514), tacacs-ds (65), talk (517), tftp (69), time (37), who
(513), xdmcp (177)
