Cisco 300 Series User Manual

Address Table Commands
153 OL-32830-01 Command Line Interface Reference Guide
5
For each Forwarding Data Base (FDB) mode, use different CLI commands to
configure static entries for IPv6 Multicast addresses in the FDB, as described in
the following table::
The following table describes the actual data that is written to the Forwarding
Data Base (FDB) as a function of the MLD version that is used in the network:
(*) Note that (*,G) cannot be written to the FDB if the mode is ip-src-group. In that
case, no new FDB entry is created, but the port is added to the (S,G) entries (if they
exist) that belong to the requested group.
If an application on the device requests (*,G), the operating FDB mode is changed
to ip-group.
You can execute the command before the VLAN is created.
Example
The following example configures the Multicast bridging mode as an ip-group on
VLAN 2.
switchxxxxxx(config)# interface vlan 2
switchxxxxxx(config-if)# bridge multicast ipv6 mode
ip-group
FDB Mode CLI Commands
mac-group
bridge multicast address bridge multicast forbidden
address
ipv6-group bridge multicast ipv6
ip-address
bridge multicast ipv6
forbidden ip-address
ipv6-src-group bridge multicast ipv6 source
group
bridge multicast ipv6
forbidden source group
FDB mode MLD version 1 MLD version 2
mac-group MAC group address MAC group address
ipv6-group IPv6 group address IPv6 group address
ipv6-src-group (*) IPv6 source and group addresses
