Cisco 300 Series User Manual

Network Management Protocol (SNMP) Commands
869 OL-32830-01 Command Line Interface Reference Guide
45
Example
The following example displays the configured SNMP groups.:
The following table describes significant fields shown above.
45.10 snmp-server user
To configure a new SNMP Version user, use the snmp-server user Global
Configuration mode command. To remove a user, use the no form of the command.
To enter the authentication and privacy passwords in encrypted form (see SSD),
use the encrypted form of this command.
Syntax
snmp-server user
username groupname {v1 | v2c | [ remote host] v3[ auth {md5 | sha}
auth-password [priv priv-password] ]}
switchxxxxxx# show snmp groups
Name Security Views
-------------
user-group
managers-group
Model
-----
V2
V2
Level
----
no_auth
no_auth
Read
-------
Default
Default
Write
-------
""
Default
Notify
-------
""
""
Field Description
Name Group name.
Security Model SNMP model in use (v1, v2 or v3).
Security Level Packet security. Applicable to SNMP v3
security only
.
Views Read View name enabling viewing the agent
contents. If unspecified, all objects
except the community-table and
SNMPv3 user and access tables are
available.
Write View name enabling data entry and
managing the agent contents.
Notify View name enabling specifying an inform
or a trap.

Cisco 300 Series Specifications

General

Model	Cisco 300 Series
Category	Switch
Dimensions	Varies by model
Weight	Varies by model
Power over Ethernet (PoE)	Available on select models
Management	Web-based GUI, SNMP, CLI
VLANs	Up to 256
Security Features	ACLs, 802.1X, Port Security
Humidity	10% to 90% non-condensing
Ports	8, 16, 24, 48
