Cisco 300 Series User Manual

IP Addressing Commands
457 OL-32830-01 Command Line Interface Reference Guide
22
10.5.230.232/24 vlan 1 UP/UP Static disable Enabled Valid
22.6 arp
Use the arp Global Configuration mode command to add a permanent entry to the
Address Resolution Protocol (ARP) cache. Use the no form of this command to
remove an entry from the ARP cache.
Syntax
arp
ip-address mac-address [ interface-id ]
no arp ip-address
Parameters
• ip-address —IP address or IP alias to map to the specified MAC address.
• mac-address —MAC address to map to the specified IP address or IP alias.
• interface-id —Address pair is added for specified interface.
Command Mode
Global Configuration mode
Default Configuration
No permanent entry is defined.
If no interface ID is entered, address pair is relevant to all interfaces.
User Guidelines
The software uses ARP cache entries to translate 32-bit IP addresses into 48-bit
hardware (MAC) addresses. Because most hosts support dynamic address
resolution, static ARP cache entries generally do not need to be specified.
Example
The following example adds IP address 198.133.219.232 and MAC address
00:00:0c:40:0f:bc to the ARP table.
switchxxxxxx(config)# arp 198.133.219.232 00:00:0c:40:0f:bc vlan100

Cisco 300 Series Specifications

General

Model	Cisco 300 Series
Category	Switch
Dimensions	Varies by model
Weight	Varies by model
Power over Ethernet (PoE)	Available on select models
Management	Web-based GUI, SNMP, CLI
VLANs	Up to 256
Security Features	ACLs, 802.1X, Port Security
Humidity	10% to 90% non-condensing
Ports	8, 16, 24, 48
