Introduction
OL-32830-01 Command Line Interface Reference Guide 40
1
Configuration Examples
Layer 2 Switch
The following example shows how to configure IP on a Layer 2 switch:
The router with IP Address 10.10.10.1 should be configured with the following
static route: ip route 172.25.13.2 /32 10.10.10.2.
Switch# configure terminal
Switch(config)# interface vlan 1
Switch(config-if)# ip address 10.10.10.2 /24
default-gateway 10.10.10.1
Switch(config-if)# exit
Switch(config)# interface loopback 1
Switch(config-if)# ip address 172.25.13.2 /32
Switch(config-if)# ipv6 address
2001:DB8:2222:7272::72/128
Switch(config-if)# exit

Cisco 300 Series Specifications

General

Model	Cisco 300 Series
Category	Switch
Dimensions	Varies by model
Weight	Varies by model
Power over Ethernet (PoE)	Available on select models
Management	Web-based GUI, SNMP, CLI
VLANs	Up to 256
Security Features	ACLs, 802.1X, Port Security
Humidity	10% to 90% non-condensing
Ports	8, 16, 24, 48
