Ethernet Configuration Commands
395 OL-32830-01 Command Line Interface Reference Guide
18
Example
The following example configures gi11 to operate in full duplex mode.
switchxxxxxx(config)#
interface gi11
switchxxxxxx(config-if)#
duplex full
18.8 negotiation
To enable auto-negotiation operation for the speed and duplex parameters and
master-slave mode of a given interface, use the negotiation Interface (Ethernet,
Port Channel) Configuration mode command. To disable auto-negotiation, use the
no form of this command.
Syntax
negotiation [
capability
[
capability2
...
capability5
]] [
preferred
{
master
|
slave
}]
no negotiation
Parameters
• Capability—(Optional) Specifies the capabilities to advertise. (Possible
values: 10h, 10f, 100h,100f, 1000f).
- 10h—Advertise 10 half-duplex
- 10f—Advertise 10 full-duplex
- 100h—Advertise 100 half-duplex
- 100f—Advertise 100 full-duplex
- 1000f—Advertise 1000 full-duplex
• Preferred—(Optional) Specifies the master-slave preference:
- Master—Advertise master preference
- Slave—Advertise slave preference
Default Configuration
If capability is unspecified, defaults to list of all the capabilities of the port and
preferred slave mode.
