Introduction
41 OL-32830-01 Command Line Interface Reference Guide
1
Layer 3 Switch with Static Routing
The following example shows you how to configure IP on a Layer 3 switch with
static routing:
The neighbor router 10.10.11.1 should be configured with the following static
route: ip route 172.25.13.2 /32 10.10.10.2.
The neighbor router 10.11.11.1 should be configured with the following static
route: ip route 172.25.13.2 /32 10.11.11.2.
The neighbor router 2001:DB8:2222:7270::1 connected to VLAN 1 should be
configured with the following static route:
ipv6 route 2001:DB8:2222:7272::72/128 2001:DB8:2222:7270::2312
Switch# configure terminal
Switch(config)# interface vlan 1
Switch(config-if)# ip address 10.10.10.2 /24
Switch(config-if)# ipv6 address 2001:DB8:2222:7270::2312/64
Switch(config-if)# exit
Switch(config)# interface vlan 2
Switch(config-if)# ip address 10.11.11.2 /24
Switch(config-if)# ipv6 address 2001:DB8:3333:7271::2312/64
Switch(config-if)# exit
Switch(config)# interface loopback 1
Switch(config-if)# ip address 172.25.13.2 /32
Switch(config-if)# ipv6 address 2001:DB8:2222:7272::72/128
Switch(config-if)# exit
Switch(config)# ip route 0.0.0.0/0 10.10.11.1
Switch(config)# ip route 10.11.0.0 /16 10.11.11.1
Switch(config)# ipv6 route 0::/0 2001:DB8:2222:7270::1
Switch(config)# ipv6 route 2001:DB8:3333::/48
2001:DB8:3333:7271::1

Cisco 300 Series Specifications

General

Model	Cisco 300 Series
Category	Switch
Dimensions	Varies by model
Weight	Varies by model
Power over Ethernet (PoE)	Available on select models
Management	Web-based GUI, SNMP, CLI
VLANs	Up to 256
Security Features	ACLs, 802.1X, Port Security
Humidity	10% to 90% non-condensing
Ports	8, 16, 24, 48
