Introduction
OL-32830-01 Command Line Interface Reference Guide 42
1
The neighbor router 2001:DB8:3333:7271::1 connected to VLAN 1 should be
configured with the static route defined immediately below.
IPv6 Route 2001:DB8:2222:7272::72/128 2001:DB8:3333:7271::2312
Without RIP
The following example describes how to configure IP on a Layer 3 switch with RIP
not running on the loopback interface:
The other routers need static routes for 172.25.13.2/32, because the route is
advertised by RIP.
Switch# configure terminal
Switch(config)# interface vlan 1
Switch(config-if)# ip address 10.10.10.2 /24
Switch(config-if)# exit
Switch(config)# interface vlan 2
Switch(config-if)# ip address 10.11.11.2 /24
Switch(config-if)# exit
Switch(config)# interface loopback 1
Switch(config-if)# ip address 172.25.13.2 /32
Switch(config-if)# exit
Switch(config)# router rip
Switch(config-rip)# network 10.10.10.2
Switch(config-rip)# network 10.11.10.2
Switch(config-rip)# redistribute connected
Switch(config-rip)# exit

Cisco 300 Series Specifications

General

Model	Cisco 300 Series
Category	Switch
Dimensions	Varies by model
Weight	Varies by model
Power over Ethernet (PoE)	Available on select models
Management	Web-based GUI, SNMP, CLI
VLANs	Up to 256
Security Features	ACLs, 802.1X, Port Security
Humidity	10% to 90% non-condensing
Ports	8, 16, 24, 48
