Spanning-Tree Commands
OL-32830-01 Command Line Interface Reference Guide 914
46
Interfaces
Name
------
gi1 1
gi1 2
gi1 3
gi1 4
gi1 5
State
------
Enabled
Enabled
Disabled
Enabled
Enabled
Prio. No
------
128.1
128.2
128.3
128.4
128.5
Cost
-----
20000
20000
20000
20000
20000
Sts
---
FRW
FRW
-
BLK
DIS
Role
----
Root
Desg
-
Altn
-
PortFast
-------
No
No
-
No
-
Type
----------
P2p (RSTP)
Shared (STP)
-
Shared (STP)
-
switchxxxxxx# show spanning-tree
Spanning tree enabled mode RSTP
Default port cost method: long
Root ID Priority
Address
36864
00:02:4b:29:7a:00
This switch is the Root.
Hello Time 2 sec Max Age 20 sec Forward Delay 15 sec
Interfaces
Name
--------
gi1 1
gi1 2
gi1 3
gi1 4
gi1 5
State
--------
Enabled
Enabled
Disabled
Enabled
Enabled
Prio.Nbr
---------
128.1
128.2
128.3
128.4
128.5
Cost
-----
20000
20000
20000
20000
20000
Sts
---
FRW
FRW
-
FRW
DIS
Role
----
Desg
Desg
-
Desg
-
PortFast
--------
-
No
No
-
No
-
Type
----------
P2p (RSTP)
Shared (STP)
-
Shared (STP)
-
switchxxxxxx# show spanning-tree
Spanning tree disabled (BPDU filtering) mode RSTP
Default port cost method: long
Root ID Priority
Address
Path Cost
Root Port
Hello Time
N/A
N/A
N/A
N/A
N/A Max Age N/A Forward Delay N/A
Bridge ID Priority
Address
36864
00:02:4b:29:7a:00
Hello Time 2 sec Max Age 20 sec Forward Delay 15 sec
