3.3.5.6 CO Line Preset Forward Attributes – PGM 147
The CO Line Preset Forward feature enables a CO line to initially ring at multiple stations and
forward to a pre-determined destination (PGM 204). The destination can be a station, Voice
Mailbox, ACD group, or Hunt group. Each CO line has a Preset Forward Timer. Each CO line
also can be assigned a VMID (Voice Mail Id) to allow sending specific VM digits when a CO line
forwards to an external VM group.
PROCEDURE:
CO PRESET FWD ATT
ENTER COL RANGE
1. Press the [PGM] button and dial 147.
01-02 CO PRE-FWD
PRESS FLEX KEY(1–3)
Use the dial-pad to enter the CO Line range. For a single
CO Line, enter the same number twice.
Select the desired Flex button; refer to Table 3.3.5.6-1.
Use the dial-pad to enter the desired value for the selected
Attribute, refer to Table 3.3.5.6-1.
Press the
[Save]
button to store the data entry.
Table 3.3.5.6-1 CO LINE PRESET FORWARD ATTRIBUTES (PGM 147)
BTN ATTRIBUTE/DISPLAY DESCRIPTION RANGE DEFAULT
1
01-02 PRESET FWD TMR
(00-99 SEC) : 00
An incoming call, which remains
unanswered for this timer, is routed
to the pre-determined Ring Table
Index, PGM 147-button 2.
00-99 Sec 00
2
01-02 RING TBL INDEX
INDEX : NOT ASSIGNED
If an incoming call remains
unanswered after the Preset Fwd
time the call is routed as defined in
the ICLID Ring Assignment table
bin entered here, refer to PGM 204.
001-250 …
3
01-02 VMID NUMBER
….
Each CO/IP line can be assigned a
VMID (Voice Mail Id) that is sent to
the VM group to identify the desired
Mailbox for the CO/IP line.
0000~9999 …
