iPECS eMG80 & eMG800 & UCP
Administration and Programming Manual Issue 1.6
47
3.3.3.3 Station Attributes IV -PGM 114
When a station uses an ISDN Line, various parameters relating to ISDN Calling Line Identification
and Connected Line Identification can be assigned for each station. In addition, when the station
is an SLT, several parameters must be set to indicate the capabilities related to the station, such
as 3.1 KHz audio for ISDN use. Refer to Table 3.3.3.3-1 for a description of the attributes and the
inputs available.
PROCEDURE:
STATION ATT 4
ENTER STA RANGE
1. Press the [PGM] button and dial 114.
100-110 STATION ATT4
PRESS FLEX_KEY (01-24)
Use the dial-pad to enter a station range (Ex. 100~110). For
a single station, enter the same number twice.
Press the desired Flex button; refer to Table 3.3.3.3-1.
Use the dial-pad to enter desired data for the attribute, refer
Press the
button to store the data entry.
Table 3.3.3.3-1 STATION ISDN ATTRIBUTES (PGM 114)
BTN ATTRIBUTE/DISPLAY DESCRIPTION RANGE DEFAULT
1
100-110 CLIP DISPLAY
(1:ON/0:OFF ) : OFF
CLIP (Calling Line Identification
Presentation), an ISDN service, sends
the number of the calling party to the
system in the call SETUP message. If
enabled here, the number will be shown
0: OFF
1: ON
OFF
2
100-110 COLP DISPLAY
(1:ON/0:OFF ) : OFF
COLP (Connected Line Id Presentation),
an ISDN service, sends the number of
the answering party to the system in the
call CONNECT message. If enabled
here, the number will be shown in the
iPECS Phone LCD.
0: OFF
1: ON
OFF
3
100-110 PROGRESS IND
(1:ON/0:OFF ) : OFF
When employing a non-ISDN terminal,
specifically a modem or analog FAX, the
ISDN call SETUP message must include
this message and the Progress
Indication
parameter should be set to “ON”.
0: OFF
1: ON
OFF
4
100-11- CLIR SERVICE
(1:ON/0:OFF ) : OFF
CLIR (Calling Line Identification
Restriction), an ISDN service, removes
calling party Id sent from the PSTN to the
called party with a RESTRICT instruction
in the SETUP message.
If enabled here, the system will send the
RESTRICT instruction to the PSTN when
an outgoing ISDN call is placed.
0: OFF
1: ON
OFF
To Next Page
