iPECS eMG80 & eMG800 & UCP
Administration and Programming Manual Issue 1.6
334
4.4.4.11 CID/CPN Attributes - PGM 151
Selecting CID/CPN Attributes will display the CID/CPN Attributes data input page. Enter a valid
CO range and click [Load] to enter the CID/CPN Attributes data. Use the check mark to indicate
which attributes to modify; data for checked attributes is stored by clicking [Save] button.
Enter CO Range
: eMG80: 1-74 / eMG800: 1-600 / UCP: 1-998
Figure 4.4.4.11-1 CID/CPN Attributes
COLP: Connected Line Presentation / CLIP: Calling Line Identification Presentation
You can set the CID password to click “Go to Setting” button. After clicking it, you will move to the
following PGM 162 and set the CID password, and then save CID password to mark tick on the
save box and click the Save button.
Setting CID Password directly
Refer to Table 4.4.4.11-1 for information on individual attributes.
Table 4.4.4.11-1 CID/CPN ATTRIBUTES
ATTRIBUTE DESCRIPTION RANGE DEFAULT
COLP Table Index
When an incoming call on an ISDN Line is answered, the
system will send caller id using the number from the
CLIP/COLP Table (section 4.4.7.2) entry defined by this
parameter. The station number is included as a suffix of
N/A
0-49
Station CLI
Station CLI
