iPECS eMG80 & eMG800 & UCP
Administration and Programming Manual Issue 1.6
35
3.3.2.6 8-Digit Table
We can support it more 4 digits for station number. Station numbering should not conflict with
numbering plan. It is consist of prefix digits and add digits. Prefix digits can have up to 4 digits
and Add digits can have up to 4 digits.
PROCEDURE:
DIGIT 8 TBL
ENTER TBL NO(01-10)
1. Press the [PGM] button and dial 238.
Digit 8 TBL 1 : Empty
Use the dial-pad to enter the desired table number.
Press the desired Flex button; refer to Table 3.3.2.6-1.
Use the dial-pad to enter the required data.
Press the
button to store the data entry.
Table 3.3.2.6-1 8-Digit Table (PGM 238)
BTN ATTRIBUTE/DISPLAY DESCRIPTION RANGE DEFAULT
1
TBL 1 : SET 8 digit
8 Digit 1 : …....
The user may be allowed to enter
the prefix digits using character
assign method. (ex : 4+0 → 4)
Up to 4 digits N/A
2
TBL 1: SET ADD DIGIT
ADD DIGIT : 0
The user can be allowed to add
digits. (ex: if it’s set 3, prefix digits +
xxx)
Up to 4 digits 0
