4.4.4.13 DCOB CO Line Attributes - PGM 153
Selecting DCOB CO Line Attributes will display the DCOB Line Attributes data input page. Enter
a valid CO range and click [Load] button to enter the DCOB Line Attributes data. Use the check
mark to indicate which attributes to modify; data for checked attributes is stored by clicking [Save]
button.
Enter CO Range
: eMG80: 1-74 / eMG800: 1-600 / UCP: 1-998
Figure 4.4.4.13-1 DCOB CO Line Attributes
Table 4.4.4.13-1 DCOB LINE ATTRIBUTES
ATTRIBUTE DESCRIPTION RANGE DEFAULT
Line Status
This parameter defines the code that the system will
send to indicate idle line status in accordance with
E1R2 specifications.
1~9 6
DNIS Service
In R2, this field determines whether system will send
caller information to PX or not.
OFF
ON
OFF
Number of CLI Digits
This parameter defines the number of digits expected
as the Calling Line Identification from digital CO lines.
01~15 10
DCOB Type
According to this type, the line can be restricted to the
type of service, incoming DID and outgoing calls
(DOD).
DID/DOD,
DOD,
DID
DID
Call Category
This parameter defines the code sent in response to a
call category request from the network in accordance
with E1R2 specifications.
1~9 1
Number of Digits
Expected from DID
circuit
This parameter defines the number of digits expected
as DID digits from digital CO lines. If set to “0”, the
number of digits defined in PGM 145 is used.
0~32 0
