iPECS UCP - PPP Attributes - PGM 205

iPECS eMG80 & eMG800 & UCP
Administration and Programming Manual Issue 1.6
168
3.3.8.6 PPP Attributes – PGM 205
In addition to remote access via an IP network connection, the system database may be
accessed remotely via MODU. The system will request a user id and password, which must
match one of the User Ids and passwords assigned. After matching id and password are entered,
the iPECS Home page is provided and Web Admin is available as explained in section 4.
PROCEDURE:
PPP ATTRIBUTES
PRESS FLEX KEY (1-7)
1. Press the [PGM] button and dial 205.
Press the desired Flex button; refer to Table 3.3.8.6-1.
Used the dial pad to enter desired data, refer to Table
3.3.8.6-1 for appropriate entries.
Press the [Save] button to store the data entry.
Table 3.3.8.6-1 PPP ATTRIBUTES (PGM 205)
BTN ATTRIBUTE/DISPLAY DESCRIPTION RANGE DEFAULT
1
PPP DEST STA
….
If the incoming capability is 64 Kbps
unrestricted digital and the called
party number matches the PPP
destination, the system will
automatically answer the call and
request PPP ID and password.
Station
number
None
2
PPP USER ID 1
likppp01
System accepts this PPP ID 1. 12 Character likppp01
3
PPP PASSWORD 1
Ipkts01
The password entered is used to
authorize PPP ID 1.
12 Character Ipkts01
4
PPP USER ID 2
likppp02
System accepts this PPP ID 2. 12 Character likppp02
5
PPP PASSWORD 2
Ipkts02
The password entered is used to
authorize PPP ID 2.
12 Character Ipkts02
6
PPP SERVER IP ADDR
10 . 0 . 0 . 3
Operator can configure PPP Server
IP Address with this option. To
apply this option, system must be
restarted.
10.0.0.3
7
PPP CLIENT IP ADDR
10 . 0 . 0 . 2
Operator can configure PPP Client
IP Address with this option. To
apply this option, system must be
restarted.
10.0.0.2
