iPECS eMG80 & eMG800 & UCP

Administration and Programming Manual Issue 1.6

3.3 Procedure for Data Entry

The following sections provide specific instructions for entering data from the Admin Station once

in the Program mode. Each section provides descriptive information, step-by-step instructions

and Tables for determining appropriate entries.

3.3.1 System ID — PGM 100

Under System ID, the country is identified using the international dial codes (NATION CODE). If

the NATION code requires changing, the system must be initialized to restructure memory and

create the country specific defaults, gain, frequencies and other system characteristics specific to

the country and regional regulatory requirements.

To change the NATION Code on eMG:

 Set the MPB Dip-switch 1 pole 2 to the ON position,

 Follow the procedure below to modify the NATION code

 Press the reset button on the KSU, power the system Off and On, or use PGM 450 to

initialize the system.

 After initialization, reset switches as needed, Dip-switch 1 pole 2 should be OFF.

A twenty-four (24) character SITE NAME and the local Area Code are also defined in this

program. The SITE NAME is primarily useful for the installer/programmer as a reference to the

customer.

In addition, under this program the system can be programmed to select one of eight (8) Flexible

Number Plans, refer to Appendix B. Individual items from the selected Numbering Plan can be

changed under Flexible Numbering Plan part A to D – PGM 106 to 109- in section 3.3.2.5.

PROCEDURE:

SYSTEM ID

PRESS FLEX KEY (1-6)

1. Press the [PGM] button and dial 100.

Select the desired Flex button (1~5), refer to Table 3.3.1-1.

For COUNTRY CODE, refer to Table 3.3.1-2 for appropriate

entries.

Use the dial-pad to enter desired System Id data. For

System Reset, button 5, press [Save] to reset the System Id

to default.

To store the System Id data press the [Save] button.

Table 3.3.1-1 SYSTEM ID (PGM 100)

BTN − DISPLAY REMARK RANGE DEFAULT

COUNTRY CODE

Refer to Table 3.3.1-2 below.

Note system must be re-initialized if

changed.

4 digits 1
