3.3.8 ISDN LINE & ICLID ROUTING DATA – PGM 200-206
Each ISDN (Integrated Services Digital Network) Line provides digital services to the end-user.
Basic Rate Lines have three (3) channels, 2 B channels and a D channel. The 2 B channels
provide 64 Kbps each, a total of 128 Kbps for “Bearer” or voice channels. The D channel provides
a 16 Kbps signaling channel. Primary Rate Lines have 23/30 64 Kbps ‘B’ channels and 1/2 64
Kbps signaling channels. For proper operation, entries are required for various attributes in PGM
200 ~ 202 to match the ISDN circuit and services from the PSTN.
3.3.8.1 ISDN Attributes – PGM 200
ISDN attributes define several characteristics of the ISDN interface. ISDN call cost services
(Advice of Charge), CLI modification, voice encoding, and other characteristics of the interface
are defined.
PROCEDURE:
SYSTEM ISDN ATT
PRESS FLEX KEY (1-3)
1. Press the [PGM] button and dial 200.
Press the Flex button for the desired Attribute; refer to Table
Use the dial pad to enter the desired Attribute data.
Press the [Save] button to store the Attribute data entry.
Table 3.3.8.1-1 ISDN LINE ATTRIBUTES (PGM 200)
BTN ATTRIBUTE/DISPLAY DESCRIPTION RANGE DEFAULT
1
CO ATD CODE (2DGT)
..
When the system is set to send the
station number with ISDN CLIP or
COLP, either the station number or
this ATD code will be sent based on
1~2 digits
2
CLI PRINT TO SERIAL
(1:ON/0:OFF) : OFF
The ISDN Calling Line Id may be
included in call records output over
the serial port assigned for “Call
Information”, PGM 175 button 5.
0: OFF
1: ON
OFF
3
DISPLAY DID INFO
(1:ON/0:OFF) : OFF
Display DID digit information on
LCD and print it to serial port.
0: OFF
1: ON
OFF
To Next Page
