iPECS eMG80 & eMG800 & UCP

Administration and Programming Manual Issue 1.6

480

4.4.9.2 LCR LDT (Leading Digit Table) - PGM 221

Selecting LCR-LDT (Leading Digit Table) will display the LCR-LDT data entry page. Select the

LDT Index range desired, blue text above the table header. Click [Save] button after changing

Value.

Enter LDT Table Index Range

: eMG80: 1-10 / eMG800: 1-32 / UCP: 1-32

Figure 4.4.9.2-1 LCR Leading Digit Table

The Leading Digits Table is used to analyze the user-dialed digits to determine an appropriate

Digit Modification Table Index. LDT Tables are provided for 10 for eMG80 system & 32 for

eMG800/UCP system. The Table is divided into bins. The applicable LCR Access Modes (LCR

Type) and the digits (up to the first 12) dialed by the user are compared with the entries in the

Leading Digit Table. In addition, indices to the Digit Modification Table are defined for each of the

three (3) Zones and Time Zones configured in the LCR Control Attributes. The following table

provides a brief description and entries for the Leading Digit Table.

Table 4.4.9.2-1 LCR LEADING DIGITS

ATTRIBUTE DESCRIPTION RANGE DEFAULT

LCR Type

This entry defines the LCR modes that will apply to this

LDT index.

Internal,

CO Line,

Both
