Table 3.3.9.10-1 VOICE MAIL DIAL (PGM 234)
BTN ATTRIBUTE/DISPLAY DESCRIPTION RANGE DEFAULT
5
VOICE MAIL 5
PREFIX OR SUFFIX (1-2)
Code sent when the voice mail is to
receive a call when the user did not
answer.
No Answer Mail
1: Prefix
2: Suffix
Any digits
P#*5P
6
VOICE MAIL 6
PREFIX OR SUFFIX (1-2)
Code sent when the voice mail is to
receive a call when a dialing error
exists.
Error Mail
1: Prefix
2: Suffix
Any digits
P#*6P
7
VOICE MAIL 7
PREFIX OR SUFFIX (1-2)
It is reserved.
1: Prefix
2: Suffix
Any digits
8
VOICE MAIL 8
PREFIX OR SUFFIX (1-2)
It is reserved.
1: Prefix
2: Suffix
Any digits
9
VOICE MAIL 9
DISCONNECT [DIAL DGT_1]
Code sent when the voice mail is to
disconnect a call.
Disconnect Mail
1: Prefix
2: Suffix
Any digits
*****
3.3.9.11 Registration & Fractional Module Table – PGM 235
When multiple iPECS eMG are located on the same LAN, it may be desirable to register add-on
devices employing the Registration Table.
PROCEDURE:
REGISTRATION TBL
ENTER TBL NO(1-5)
1. Press the [PGM] button and dial 235 and enter Table
number (Ex.1).
REG TBL 1: NO MAC INFO
MAX PORT : 00, DEV ID: . . . .
Use the dial-pad to select a Table entry (1~5).
Press the desired Flex button; refer to Table 3.3.9.11-1.
Use the dial-pad to enter the desired data, refer to Table
3.3.9.11-1.
Press the [Save] button to store the data entry.
Table 3.3.9.11-1 MAC REGISTRATION (PGM 235)
BTN ATTRIBUTE/DISPLAY DESCRIPTION RANGE DEFAULT
1
TBL 1: SET MAC ADDR
MAC 1: . . . . . . . . . . . . . . . .
Enter the MAC address of the
device to register.
2
TBL 1: SET MAX PORT
NO OF PORT : 00
Enter maximum number of ports
(channels) for the device. For a 00
entry the system will accept
physical port number.
00-99 00
