3.3.8.4 ICLID Route Table – PGM 203
The system can employ ICLID (Incoming Calling Line Id) to determine the routing of incoming
external calls. Each CO/IP Line and ACD group may be assigned to employ ICLID routing. The
system will compare the received ICLID to entries in the ICLID Route Table and, if a match is
found, will route the call to the destination indicated by the index (bin) number of PGM 204.
PROCEDURE:
ICLID ROUTE TABLE ATT
ENTER BIN NO (001-250)
1. Press the [PGM] button and dial 203 and enter the bin
number (Ex.001).
ICLID ROUTE TABLE 001
PRESS FLEX KEY (1-4)
To program ICLID Route table, dial Bin No (001 – 250).
Press the Flex button for the desired ICLID Table entry; refer
to Table 3.3.8.4-1.
Use the dial pad to enter the desired Table data
Press the [Save] button to store the Table data entry.
Table 3.3.8.4-1 ICLID ROUTE INDEX (PGM 203)
BTN ATTRIBUTE/DISPLAY DESCRIPTION RANGE DEFAULT
1
ROUTE TABLE 001
INDEX : NOT ASSIGNED
Index to the ICLID Ring Assignment
Table PGM 204 that determines the
call routing.
001~250 Not assigned
2
TABLE 001 ICLID NUMBER
…………………….
ICLID (Incoming Caller Id) to match
for the index. If the Caller Id
matches the Table entry, the index
is used to select the route from
PGM 204.
24-digits 0 ~ 9
& ‛*’ and ‛#’ as
a wild-card.
None
3
TABLE 001 ICLID NAME
……………………..
ICLID name that is sent by the
system to the destination for the
ICLID routed call.
12.Character None
4
TABLE 001 ICLID TONE
..
If the ICLID Number is matched
with CID of caller, the Ring tone is
followed this ICLID Tone.
2 digits.01~12 None
