4.4.5.10 LED Flashing Rate - PGM 170
Selecting LED Flashing Rate will display the data entry page. Click [Save] button after changing
Value.
Figure 4.4.5.10-1 LED Flashing Rate
The LED flash rate for various functions and states can be assigned any one of the system‘s 15
signals. The various functions and states are shown in the following table. The 15 flash signals
available in the system are shown in the table ‘LED flash rate’.
Table 4.4.5.10-1 LED INDICATION
ATTRIBUTE DESCRIPTION RANGE DEFAULT
CO Incoming Ring CO button Incoming ring flashing rate. 00-14
FLASH 30 IPM
(2)
CO Transfer Ring CO button transfer ring flashing rate. 00-14
FLASH 120 IPM
(10)
COL Queue Ring CO button queue call back ring flashing rate. 00-14
FLASH 240 IPM FLUTTER
(6)
